Medical Conductive Gel Manufacturer | Ultrasound & TENS Gel (OEM/ODM) - TOP-RANK
Premium water-based conductive gel for TENS, EMS, Ultrasound, and IPL devices. ISO 13485 certified manufacturer offering custom viscosity, hypoallergenic formulas, and private label packaging.
Product Overview
In the field of electrotherapy and medical imaging, the quality of the conductive medium determines the stability of the signal and the comfort of the patient. TOP-RANK Conductive Gel is a premium, high-viscosity coupling agent designed to minimize contact impedance between the electrode/transducer and the skin.
As a dedicated hydrogel source factory, Top-Rank maintains large-scale batch production capacity in our cleanroom facilities to meet global OEM demand. Unlike standard gels, our proprietary "Micro-Bubble Free" vacuum mixing technology ensures superior acoustic transmission and electrical conductivity.
Whether you need a high-tack gel for long-term monitoring pads or a smooth-glide couplant for ultrasound diagnostics, we can engineer the exact rheology (flow properties) to match your device's requirements.
Why Our Formula is Superior
Our R&D team has perfected a water-soluble formula that solves the common pain points of generic gels:
- Zero Signal Artifacts: Salt-free formulation prevents electrode corrosion and signal noise, extending the lifespan of your rubber or carbon electrodes.
- Optimal Viscosity: Non-drip texture that stays in place during treatment but glides effortlessly during probe movement.
- Skin Protection: Hypoallergenic and bacteriostatic; free from parabens, alcohol, and formaldehyde. Safe for sensitive skin and prolonged use.
- Easy Cleanup: Non-greasy and water-soluble; wipes off clean with a tissue without leaving sticky residue or staining clothes.
Customization Capabilities (OEM Service)
We offer more than just a standard clear gel. Build your own brand with our flexible manufacturing options:
1. Formula Customization
- Viscosity Level:
High Viscosity: For ECG monitoring and localized TENS/EMS.
Medium Viscosity: For general Ultrasound and Physiotherapy.
Low Viscosity: For automated refilling systems.
- Active Ingredients: Add Aloe Vera, Vitamin E, or Hyaluronic Acid for beauty/microcurrent applications (Hydrating Conductive Gel).
- Appearance: Custom colors (Blue, Pink, Clear) and scents to differentiate your brand.
2. Private Label Packaging
- Single-use Sachets: 10g / 15g / 20g (Ideal for device starter kits).
- Retail Tubes: 60ml / 100ml / 250ml soft tubes with flip-top caps.
- Clinical Bottles: 250ml / 500ml / 1000ml bottles (squeeze or pump).
- Bulk Containers: 5L Cubitainers (Foldable jerrycans) for hospital refills.
Technical Specifications
| Feature | Specification |
| Base | Water-soluble polymer matrix |
| pH Value | 5.5 – 8.0 (Neutral, skin-compatible) |
| Viscosity | 15,000 – 70,000 cps (Customizable) |
| Acoustic Impedance | 1.50 – 1.70 MRayl (Matches human tissue) |
| Sound Velocity | 1520 – 1620 m/s |
| Conductivity | Optimized for < 100 Ω impedance reduction |
| Shelf Life | 3 Years (Sealed) |
| Storage | Room temperature, avoid direct sunlight |
Applications
This universal conductive gel is engineered for a wide range of medical and aesthetic devices:
Electrotherapy
TENS units, EMS muscle stimulators, EMG biofeedback.
Diagnostic Imaging
Ultrasound (B-mode, Doppler), Echocardiography.
Aesthetic Treatments
Microcurrent facials, Radio Frequency (RF) skin tightening, IPL hair removal, Cavitation slimming.
Monitoring
ECG stress tests, Holter monitoring, EEG caps (requires specific high-salt formulation).
Inquiry
Optimize Your Device Performance
Don't let poor conductivity limit your technology.
Request samples for viscosity and conductivity testing or discuss formula matching with our engineering team today.
