TENS-806 is an advanced electrical stimulation machine specifically designed to provide relief from pain, alleviate discomfort, and promote rehabilitation. With its advanced features and user-friendly operation, the TENS-806 offers effective therapy and a comfortable user experience.
Specifications
|
Device name |
TENS-806 |
|
Power sources |
3.7 V Li-ion battery |
|
Power supply |
Input: 100-240V AC, 50/60Hz,0.2A; Output: 5V DC, 300mA |
|
Output channel |
Dual channel |
|
Waveform |
Bi-phase square-wave pulse |
|
Output current |
Max. 120mA (at 500ohm load) |
|
Output intensity |
0 to 40 levels, adjustable |
|
Treatment mode |
TENS,EMS |
|
Number of programs |
26 program |
|
Pulse rate |
2Hz ~ 120Hz |
|
Pulse width |
50uS ~ 300uS |
|
Treatment time |
5 minutes ~ 90 minutes |
|
Operating condition |
5° C to 40° C with a relative humidity of 15%-93%, |
|
Storage condition |
-10° C to 55° C with a relative humidity of 10%- |
|
Dimension |
109*55*18mm (L x W x T) |
|
Weight |
About 73g |
|
Automatic shutof |
1 minute |
|
Classification |
BF type applied part, internal power equipment, IP22 |
|
Size of electrodes pad |
40x40mm, square |
|
Output precision |
±20% error is allowed for all the output parameters |
Product Detail
TENS-806 is an advanced stimulator machine specifically designed to provide relief from pain, alleviate discomfort, and promote rehabilitation. With its advanced features and user-friendly operation, the TENS-806 offers effective therapy and a comfortable user experience.
Equipped with a 2.5-inch backlit display, the device provides clear visibility of all functions and parameters. Its low standby power consumption design of 3 microamps extends battery life and conserves energy.
The TENS-806 utilizes an 8-bit high-performance, low-power microcontroller for stable and reliable control. It offers multiple therapy modes, including low-frequency therapy, which combines deep massage, pain relief, and non-invasive treatment. The independent display and control of the 2 channels allow simultaneous treatment of different body areas, providing a personalized treatment experience.
Featuring a graphical display of 6 body areas including neck, shoulder, waist, elbow, knee, and hip, the TENS-806 allows targeted treatment based on individual needs.
The device offers 20 levels of intensity adjustment, allowing users to choose the appropriate treatment strength. The treatment time can be adjusted continuously, with a maximum duration of 60 minutes, enabling users to customize their therapy sessions according to their specific needs.
Our stimulator machine is suitable for a wide range of users, including those seeking relief from muscle pain, improved blood circulation, and enhanced mobility. Whether it's office workers, sports enthusiasts, or individuals experiencing prolonged tension, the TENS-806 provides comfortable, safe, and convenient pain relief and rehabilitation therapy.
As a high-performance e-stim machine, the TENS-806 holds significant potential in the fields of pain management and rehabilitation. Its advanced features and superior design make it an essential therapeutic tool for every and medical facility. Let the TENS-806 be your trusted companion in pain relief and healing!
Qualification Certificate: ISO13485/FDA OTC/MDSAP/CE
Features
1. Independent display and control of dual-channel treatment mode
2. Graphical display of 6 body parts: Back of Neck/Shoulder/Waist/Elbow/Knee/Buttocks
3. 20-step intensity adjustment
4. Treatment time up to 60 minutes, continuous (stepper) adjustable
5. Waterproof grade at least IP22, drop prevention.
6. Button lock/unlock function.
7. There are 9 programs for user choose, the treatment time can be adjusted within 5-60 minutes，The device stops automatically after treatment.
FAQ
Q1: What is an electrical stimulation machine?
A1: An electrical stimulation machine is a device that uses electrical impulses to stimulate muscles, nerves, or specific body parts for therapeutic purposes.
Q2: How does an electrical stimulation machine work?
A2: The electrical stimulation machine works by delivering controlled electrical currents to targeted areas of the body, causing muscle contractions and promoting pain relief, muscle strengthening, and rehabilitation.
Q3: Can I use an electrical stimulation machine at home?
A3: Yes, there are electrical stimulation machines available for home use. However, it is important to consult with a healthcare professional to determine the suitability and proper usage of the machine.
Q4: What is the price range of an electrical stimulation machine?
A4: The price of an electrical stimulation machine can vary depending on the brand, features, and quality. It is recommended to research different options and compare prices to find the best stim machine price that suits your budget and needs.
Q5: What are the benefits of using an electrical stimulation machine?
A5: Using an electrical stimulation machine can have various benefits, including pain management, muscle rehabilitation, improved blood circulation, muscle toning, and relaxation. However, individual results may vary, and it is important to follow the instructions and guidelines provided with the machine.
