product Specifications
|
Device name |
TENS-806 |
|
Power sources |
3.7 V Li-ion battery |
|
Power supply |
Input: 100-240V AC, 50/60Hz,0.2A; Output: 5V DC, 300mA |
|
Output channel |
Dual channel |
|
Waveform |
Bi-phase square-wave pulse |
|
Output current |
Max. 120mA (at 500ohm load) |
|
Output intensity |
0 to 40 levels, adjustable |
|
Treatment mode |
TENS,EMS |
|
Number of programs |
26 program |
|
Pulse rate |
2Hz ~ 120Hz |
|
Pulse width |
50uS ~ 300uS |
|
Treatment time |
5 minutes ~ 90 minutes |
|
Operating condition |
5° C to 40° C with a relative humidity of 15%-93%, |
|
Storage condition |
-10° C to 55° C with a relative humidity of 10%- |
|
Dimension |
109*55*18mm (L x W x T) |
|
Weight |
About 73g |
|
Automatic shutof |
1 minute |
|
Classification |
BF type applied part, internal power equipment, IP22 |
|
Size of electrodes pad |
40x40mm, square |
|
Output precision |
±20% error is allowed for all the output parameters |
1. Independent display and control of dual-channel treatment mode
2. Graphical display of 6 body parts: Back of Neck/Shoulder/Waist/Elbow/Knee/Buttocks
3. 20-step intensity adjustment
4. Treatment time up to 60 minutes, continuous (stepper) adjustable
5. Waterproof grade at least IP22, drop prevention.
6. Button lock/unlock function.
7. There are 9 programs for user choose, the treatment time can be adjusted within 5-60 minutes,The device stops automatically after treatment.
features
Multi-Mode Regulation
The Top-Rank TENS-806 portable electric stimulation machine is an excellent choice for pain relief therapy, featuring 36 modes. This TENS electronic massager can help alleviate sciatic nerve pain and muscle soreness caused by sports, overwork, or normal household activities. Especially in DIY mode, the massager can provide more customized and personalized pain management treatment according to your needs.
Dual Channels and Independent Intensity
EMS Muscle Stimulator: With 2 independent channels, 36 therapeutic modes, 20 levels of intensity adjustment, and time control, it achieves optimal relaxation and pain management. You can use 4 electrode pads simultaneously. The most effective method for muscle recovery and back pain relief. Each channel has different intensity settings, targeting various massage pain areas without causing a shock sensation.
Extra Care and Considerate Design
The large, backlit LCD screen is more suitable for the elderly to read. This portable electric stim machine has multiple timer settings, allowing us to set the treatment time according to the needs of the body part. Using a belt clip, you can simply place it on your waist when exercising or doing housework without affecting your use. The standard 2mm connector cable and TENS machine pads are commonly used in the medical field, making it easier for you to find compatible accessories.
100% Satisfaction Guarantee
The TENS Muscle Stimulator is an ideal gift for family members, loved ones, and yourself. You will receive 1 TENS machine, 4 square electrode pads (4cm x 4cm), 2 cables, 3 batteries, 1 premium portable bag, and 1 professional user manual. Our TENS-806 device comes with a 24-month warranty and lifetime technical support. If you have any questions, please feel free to contact us. We will make every effort to provide unique, high-quality, and thoughtful 24-hour online customer service.
fAQ
1.Can you do electrical muscle stimulation at home?
An EMS unit (like a Powerdot, Compex, Tone-A-Matic, or Top-Rank TENS-806) is a device that delivers this in the comfort of your own home. This stimulation creates muscle contractions that can be quick and frequent, fast with long pauses, or contractions that are held for several (uncomfortable) seconds or minutes at a time.
2.What type of electrodes pads does the electrostim machine fit?
It's quite easy to find compatible electrodes (2mm pin-in connector tens unit pads) on the market for you to choose from. Also, this package will include 4X 2" Square pads.
3.How to connect Tens Unit replacement pads with the lead wires correctly?
When using 1/4 wire, you could use 2 pads or 4 pads at the same time, if you use 2 pads, please make sure 2 pads are connected on the same wire with 1 pad for white and 1 pad for the blue.
4.Which groups of people is this machine not suitable for?
Not suitable for pregnant women or heart disease and hypertension patients, and not safe for people with pacemakers. Please read TENS-806 Muscle Stimulator USER MANUAL carefully or consult with your physician before purchasing or using this device.
5.What are the advantages of a pin plug electrode over a button electrode?
Compared to the button-style electrodes and lead wires, 2mm pin plug electrodes patches and lead wires are easier to be connected or detached without any further pain from installment even when the electrodes pads are on your body.
6.How to use a portable electrical muscle stimulation machine?
Typically, you just need to attach the device to the targeted muscle area, adjust the appropriate current intensity and mode, and start your training.
